Raptor 90 LED 20.5" Light Bar

Raptor 90 LED 20.5" Light Bar

Regular price $405.00 AUD
Regular price Sale price $405.00 AUD
Sale Sold out
Shipping calculated at checkout.
Colour
Beam Type

Raptor 90 LED 20.5 Light Bar

The RAPTOR LED Light Bars are manufactured from high pressure extruded aluminium, giving an extremely strong but light body. This, along with a high impact polycarbonate lens make the Raptor light bars exceptionally tough.

The open-optic reflector gives a combination beam with very good distance and peripheral width of 100from one lamp type.

To ensure maximum driver comfort the light bars are available with either 4000k or 5700k Colour Temperature.

All RAPTOR lamps come complete stainless steel pivot mounting brackets and stainless steel fixings. As with all Raptor products, the light bars are manufactured in Australia and covered by a 3-year warranty for total peace of mind.

  • Made in Australia Designed and built for some of the toughest environments on earth.
  • Available with either 4000k or 5700k Colour Temperature
  • 3 Year Warranty
  • Suits DV12H Harness Sold Separately

Need a Wiring Diagram?
Get One Here

90W Raptor Light Bar Specifications
Wattage 90 Watts
Light Source 18 x 5w LED's
Light Output Raw 10,800 Lumens
Light Output Effective 8,650 Lumens
Voltage 9-36V
Current Draw 6.7A @ 13.5V
Operating Temp. -40 to 80 Deg C
Waterproof Rating IP67
Connector Type Plugs 2 Pin Heavy Duty Deutsch
Housing Aluminium
Lens Construction Polycarbonate
Bracket Stainless Steel
Colour Temperature 4000K or 5700K
Lifespan 50,000 Hours
Dimensions 523 x 45 x 73mm
Net Weight 1.7kg
Mounting Suitable Side Mounts
Beams Type Combo or Spread
Warranty 3 Years
Harness Harness not included, purchased separately. Harness to suit: DV12H
Part Number
Combo, 5700K RAP090LBv2
Spread, 5700K RAP090LBSv2
Combo, 4000K RAP090LB4v2
Spread, 4000K RAP090LB4Sv2


Made in Australia - Designed and built for some of the toughest environments on earth. Available with either 4000k or 5700k Colour Temperature 3 Year Warranty Suits DV12H Harness Sold SeparatelyMade in Australia - Designed and built for some of the toughest environments on earth. Available with either 4000k or 5700k Colour Temperature 3 Year Warranty Suits DV12H Harness Sold Separately

Dispatched within 1-3 Business Days (Excluding Custom-Made)
